TCL VOICE IN Air Conditioner S09P9S1 2.5 kW. Smart Wi-Fi Control
T-AI Energy Saving: T-AI technology allows the compressor to proactively adjust its operating frequency, focusing most of the cooling power on temperature regulation rather than unnecessary supercooling. Data was tested by SGS, with the air conditioner operating in AI energy-saving mode for a cumulative total of 3 hours in cooling mode. Actual performance may vary depending on the environment. Compared to models without AI energy-saving technology, the TCL VoxIN can achieve an energy savings rate of over 37%.
Power Consumption Monitoring: The TCL HOME app provides users with a real-time graph of their power consumption, allowing them to monitor and optimize their air conditioner usage. The three-speed generator mode controls the compressor to regulate current and energy consumption at three different levels, optimizing energy use and enabling significant electricity savings.
Equipped with a wide-amplitude, double-louver air deflector, it optimizes cooling by ensuring powerful airflow reaches every corner of your room. The large 108 mm diameter tangential fan delivers a powerful, long-range airflow for a remarkable cooling experience. Self-cleaning at 56°C, the evaporator undergoes a self-cleaning process that includes dew formation, frosting, defrosting, and drying to eliminate bacteria. Additionally, the outdoor unit's reverse function automatically removes dust, ensuring cleaner airflow and promoting healthier breathing.
Indoor Unit
Type: Reversible Air Conditioner, Inverter
Climate Control: T1
Remote Control
Power Supply: Single Phase, 220–240 V~50 Hz
Voltage Range: 165–265 V
Nominal Cooling Capacity: 2,675 W (940–3,800 W)
Nominal Cooling Capacity (Nominal Power Input): 706 W (240–1,380 W)
Nominal Current: 3.3 A (1.2–8.0 A)
Nominal Heating Capacity: 3,630 W (940–4,200 W)
Nominal Heating Capacity (Nominal Power Input): 960 W (240–1,550 W)
Nominal Current: 4.4 A (1.2–9.0 A)
Dehumidification Capacity: 1.5 liters/hour
Level Indoor sound level: 42/36/32/27/22 dB(A)
Indoor unit – Dimensions (W x D x H): 808 x 305 x 209 mm
Indoor unit – Packaging (W x D x H): 880 x 375 x 275 mm
Indoor unit – Net weight/Gross weight: 9.7/12 kg
Outdoor unit
Outdoor sound level: 51 dB(A)
Compressor type: Rotary compressor
Airflow (indoor, top): 560/560 m³/h
Refrigerant piping – Maximum length: 15 meters
Refrigerant piping – Maximum height difference: 10 meters
Refrigerant: R32/0.57 kg
Ambient temperature: -15 to 56 °C
Outdoor unit dimensions (W x D x H): 777 x 498×290 mm
Carton dimensions for the outdoor unit (L × W × H): 838×338×54 mm
Net weight: 22 kg
Gross weight: 25 kg
