Panasonic WH-WDG16ME5 16.0 kW Monobloc Heat Pump (230 V) R290

Panasonic WH-WDG16ME5 16.0 kW Monobloc Heat Pump (230 V) R290

The Panasonic WH-WDG16ME5 unit is part of the Aquarea T-CAP M range, a generation of high-performance air-to-water heat pumps using the more efficient and environmentally friendly R290 refrigerant. Its modular design and constant 16 kW output make it a versatile and robust solution for homes with high heating requirements.

Thanks to its T-CAP (Total Capacity) system, this model maintains its heating capacity even in outdoor temperatures as low as -28°C, without needing to activate the electric heating elements. It also provides domestic hot water temperatures up to 75°C, ideal for existing radiators during renovations and for demanding new construction projects.

With a SCOP of up to 6.47 in warm climates and an A+++ energy rating at 35°C, the unit guarantees low electricity consumption year-round. Its variable-speed water pump, flow meter, and optional accessories such as thermostats and anti-freeze valves ensure optimal performance and simplified installation.
Connectivity is also a key feature; it is compatible with Aquarea Smart Cloud and Service Cloud, enabling remote system control from anywhere, as well as integration with home automation systems or BMS installations.

Features
Technology and Environmental Efficiency
Uses R290, a natural refrigerant with a very low GWP and high thermodynamic efficiency. High-performance monobloc hydraulic unit, simplified installation, and no connection to the refrigeration network required.
Ideal for residential projects requiring durability, efficiency, and low emissions.
Compatible with underfloor heating, low-temperature radiators, and fan coil units.
Designed for integration with domestic hot water tanks, solar systems, and smart remote controls.
Suitable for new builds or energy-intensive renovations.
Thermal performance (EN14825)
Heating capacity: 12.10 kW (35°C) / 12.10 kW (55°C)
COP: 4.78 (35°C) / 3.03 (55°C)
SCOP: 4.58 (35°C) / 3.57 (55°C)
Energy class: A+++ (35°C) / A++ (55°C)
Heating capacity: 16.00 kW (35°C) / 14.70 kW (55°C)
COP: 4.31 (35°C) / 2.72 (55°C)
SCOP: 4.46 (35°C) / 3.57 (55°C) 3.57 (55°C)
Energy efficiency class: A+++ (35°C) / A++ (55°C)
Cooling performance (EN 14511-2)
Cooling capacity: 9.00 kW
EER: 3.92
Dimensions (W x H x D): 1200 x 1500 x 370 mm
Weight: 160 kg
